SIDE POCKET MANDREL OVAL TYPE

Description

The side pocket mandrel oval type is used for installing 1 "or 1.5" wireline retrievable flow control device. After the mandrel is lowered into the designated position by tubing, standard wireline tools can be used to running and pulling the wireline retrievable flow control device. This mandrel is equipped with a orienting sleeve and a discriminator. The materials of the side pocket mandrel oval type include L80 and L80-13Cr. The connection can be customized.

Feature and Advantage

• Simple structure, convenient and reliable use

• With a orienting sleeve and a discriminator

• Same drift ID with tubing

• Oval body

• Use below 302℉

Application

• Gas lift production

• Single-string or dual-string completion
